Product Description

Asus ROG STRIX Z490-G GAMING (WI-FI), Intel Z490, 1200, Micro ATX, 4 DDR4, XFire, HDMI, DP, AX Wi-Fi, 2.5G LAN, RGB Lighting, M.2

Motherboard Type

Desktop

Form Factor

Micro ATX

Socket

Intel 1200

Chipset

Intel Z490

CPU Support

Click here for CPU support

RAM Technology

DDR4 (Dual Channel)

RAM Slots

4 x DIMM

RAM Speeds

4800(O.C.)/4600(O.C)/4500(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz

Maximum Memory

128GB

Graphics

Supports Intel HD Graphics

Graphics Ports

1 x HDMI
1 x DisplayPort

Multi-GPU Support

Supports AMD 2-Way CrossFireX Technology

PCI/PCI Express

Intel 10th Gen Processors
1 x PCIe 3.0 x16 (x16 mode)

Intel Z490 Chipset
1 x PCIe 3.0 x16 (max at x4 mode)
1 x PCIe 3.0 x1

Storage

6 x SATA III
1 x M.2 (2242/2260/2280/22110) - PCIe
1 x M.2 (2242/2260/2280) - SATA & PCIe

RAID

RAID 0, 1, 5, 10

Wireless

Intel Wi-Fi 6 AX201
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
Support 1024QAM/OFDMA/MU-MIMO
Supports up to 2.4Gbps max data rate
Supports dual band frequency 2.4/5 GHz
Supports channel bandwidth: HT20/HT40/HT80/HT160
Supports CNVI interface
Bluetooth v5.1

LAN

2.5GB LAN

Audio

ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A

USB Ports Supported

2 x USB 3.2 Gen2 (1 Type-A & 1 Type-C at back)
6 x USB 3.2 Gen1 (4 at back, 2 at mid-board)
6 x USB 2.0 (2 at back, 4 at mid-board)
1 x USB 3.2 Gen2 Type-C front panel connector

Back Panel I/O Ports

1 x Intel I225-V 2.5Gb Ethernet
1 x DisplayPort
1 x HDMI
2 x USB 3.2 Gen2
4 x USB 3.2 Gen1
2 x USB 2.0
1 x Optical S/PDIF out
1 x USB BIOS FlashBack Button
1 x ASUS Wi-Fi Module
5 x Gold-plated audio jacks

Internal I/O Connectors

1 x CPU Fan
1 x CPU OPT Fan
2 x Chassis Fan
1 x W_PUMP+
2 x Aura RGB Strip
2 x Addressable Gen2
1 x USB 3.2 Gen2
1 x USB 3.2 Gen 1
2 x USB 2.0
1 x M.2 Socket 1
1 x M.2 Socket 2
6 x SATA 6Gb/s



1 x 24-pin EATX
1 x 8-pin ATX 12V
1 x 4-pin ATX 12V
1 x Front audio
1 x System panel
1 x Thermal sensor
1 x CPU OV
1 x Clear CMOS jumper
1 x VRM_HS_FAN

Accessories

4 x SATA 6Gb/s cables
1 x ROG Strix stickers
1 x Cable ties pack
1 x Ext Cable for RGB strips (80 cm)
1 x Ext cable for Addressable LED
1 x ROG Thank you card
1 x 2-in-1 Rubber pad
1 x Wi-Fi moving antenna
1 x M.2 SSD screw package
1 ROG key chain

Additional Features

See Overview

Package Type

Retail

Package Weight

1.1400 kg

Warranty

3 Years

Asus ROG STRIX Z490-G GAMING (WI-FI), Intel Z490, 1200, Micro ATX, 4 DDR4, XFire

£220.00Price
